Barnes 8SHTM 28 Frame Seal & Gasket Kit

Seal and Gasket Kit for a Barnes Series 8SHTM 28 Frame Solids Handling Submersible Pumps. Includes:

• 18-8 Stainless Steel Screw, SHCS, M12 x 1.75 x 25 (#127223)
• 420 SS Pin, Spring, .125 diameter x .50 in. large (#127248)
• Seal, Shaft, Outer (#125852)
• 420 Stainless Steel Ring, Retaining, EXT, 5100-177-H-SS (#129381)
• 303 Stainless Steel Key, ¼ x ¼ x 1½ in. (#Q21-20-J8)
• 18-8 Stainless Steel Screw, SHCS, M12 x 1.75 x 30 (#136284)
• Screw, SKT, FCHS, M10 x 1.5 x 20 (#125850)
• Stainless Steel Plug, Pipe, 0.375-18NPT (#014270-SS)
• AISI 1020 Pin, Dowel, 7/16 in. D, 5/8 in. large (#138545)
• PH 15-7 Mo Stainless Steel Ring, Snap, Tru-Arc, 5100-175 (#029863)

KIT,SEAL&GASKET,SH,210FR
